规格

•

• Interface standard: Compliant with USB specification Ver3.2 Gen1 (USB3.1Gen1/USB3.0) (Upward compatible with USB Ver2.0/1.1)
• 5Gbps, 480Mbps, 12Mbps, 1.5Mbps (theoretical)
• connector shape
• USB Type-C (PC side)
• USB3.2 Gen1 (USB31/3.0) Type-C connector female x 1 (upstream)
• USB3.2 Gen1 (USB31/3.0) One female Type-C connector (downstream)
• USB3.2 Gen1 (USB31/3.0) 3 female A connectors (downstream)
• Total ports: 4 ports
• Power: Both self-powered and bus-powered
• supply current
• USB3.2 Type-C connector (for PC connection)/USB PD support (up to 85 W)
• USB3.2 Type-C connector/up to 900 mA
• USB3.2 A connector/up to 900 mA per port (up to 2000 mA total for 3 ports)
• PD Support: Support
• Destination connector: RJ-45, HDMI, Audio
•

• Standards: IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T)
• *Communication speed 1000BASE-T is supported only when USB3.2 Gen1 (31/3.0) is connected.
• *To use 1000BASE-T communication, devices such as hubs, modems, and cables must also support 1000BASE-T.
• Theoretical transmission speeds: 1000Mbps, 100Mbps, 10Mbps
• Communication mode: Full duplex/Half duplex
• access methods: CSMA/CD
• Supported protocols: IPv4, IPv6
• Port shape: RJ-45 port (Auto MDI/MDI-X) with Auto-Negotiation
• < Video Output Port >
• Port Shape: HDMI Type A (19pin) Female x 2
• Supported resolutions: 1 unit Maximum resolution when connected/3840 x 2160 (4 K/60 Hz) x 2 units Maximum resolution when connected/3840 x 2160 (4 K/30 Hz) x 2 units
• *Your PC must support DisplayPort Alt Mode (DP1.4 or higher).
• Maximum supported resolution: 4 K/60 Hz
• Dual Display Output: Supported
• < Audio >
• Jack Shape: 3.5 mm 4 Pole Mini Jack x 1
• < Card Reader >
• Slot: microSD card, SD memory card
• *Supports SD/SDHC/SDXC
• Maximum supported media (SD memory card): 512GB
• Supported media (microSD card): 512GB
• < Common specifications >
• Operating Temperature: 5°C~40°C
• Operating humidity: 10% to 85% non-condensing
• Cable length: 0.5 m
• Size: W48 x D70 x H130mm
• Weight: about 310 g
• Comprises: USB Type-C cable (USB3.2/5 A compatible) (50 cm), Owner's Manual (Warranty).
