规格

•

• Interface standard: Compliant with USB specification Ver3.2 Gen1 (USB31/3.0) (Upward compatible with USB Ver2.0/1.1)
• *USB3.2 Gen1 is the same standard as USB31/3. 0 was renamed by USB-IF (USB Implementers Forum).
• 5Gbps, 480Mbps, 12Mbps, 1.5Mbps (theoretical)
• Connector shape (downstream): USB3.2 Gen1 (USB31/3.0) A connector female x 1, USB Type-C connector female x 1
• Connector Shape (Upstream): USB3.2 Gen1 (31/3.0) Type-C Connector Male
• Connector shape (PC side): USB Type-C
• Power: Both self-powered and bus-powered
• *It can also be used as self-power by using the PD-compatible AC adapter attached to the PC main unit.
• *If you use an AC adapter of 45 W or less, the computer may not enter the charging mode.
• Supply current: 830 mA max (total of all ports/at bus power)
• *If the current consumption of the connected device exceeds the supply current of the product, the product may not operate properly with the bus power.
• Total ports: 2 ports
• PD Support: Support
• PD Specifications: 100 W20V 5 A
•

• Standards: IEEE 802.3 (10BASE-T Ethernet), IEEE 802.3u (100BASE-TX Fast Ethernet), IEEE 802.3ab (1000BASE-T)
• *Communication speed 1000BASE-T is supported only when USB3.2 Gen1 (USB31/3.0) is connected.
• Communication mode: Full duplex/Half duplex
• access methods: CSMA/CD
• Port shape: RJ-45 port (Auto MDI/MDI-X) with Auto-Negotiation
• Supply voltage: 5 V
• < Common specifications >
• Cable Length: Approx. 50 cm
• Accessories: Instruction Manual, Surface Fastener
• Product size: W28 x D59.7 x H23.5mm
• Product Weight: Approx. 39 g
