规格

•

• Interface standard: Compliant with USB specification Ver3.2 Gen1 (USB31/3.0) (Upward compatible with USB Ver2.0/1.1)
• *USB3.2 Gen1 (USB31/3.0) is the same standard as USB31/3.
• Communication speed: 5Gbps/480Mbps/12Mbps/1.5Mbps (theoretical)
• connector shape
• USB3.2 Gen1 (USB31/3.0) 3 female A connectors (downstream)
• USB3.2 Gen1 (31/3.0) Type-C connector Male (upstream)
• USB Type-C (PC side)
• power: bus power
• Supply current: 830 mA max (total of all ports)
• *If the current consumption of the connected device exceeds the supply current of the product, the product may not operate properly with the bus power.
• Number of ports: 3 ports
•

• Standards: IEEE 802.3 (10BASE-T Ethernet), IEEE 802.3u (100BASE-TX Fast Ethernet), IEEE 802.3ab (1000BASE-T)
• *Communication speed 1000BASE-T is supported only when USB3.2 Gen1 (USB31/3.0) is connected.
• Communication mode: Full duplex/Half duplex
• access methods: CSMA/CD
• Port shape: RJ-45 port (Auto MDI/MDI-X) with Auto-Negotiation
• Supply voltage: 5 V
• < Common specifications >
• Size: Approx. W80 x D40 x H14.5mm
• Weight: about 40 g
• Cable length: 0.15 m
• Set Contents: Instruction Manual, Surface Fastener
