规格

• Interface:
• RS-232C: EIA/TIA-232-F Standards compliant
• Ethernet: Ethernet IEEE802.3/802.3u/802.3az/802.3RMII compliant 100BASE-TX/FX half-duplex/full-duplex (automatic detection)
• PoE — IEEE802.3at Type1 (802.3af) compliant PoE powered device (PD)
• RS-232C Transceiver: MaxLinear SP3232ECY (or equivalent)
• Ethernet connector: 1 x RJ-45
• RS-232C Connector: 1 D-Sub9Pin (Male)
• Communication protocol: TCP/IP
• RS-232C I/O Level:
• Driver: High Level Output: +5 V (min)/+5.4 V (TYP), Low Level Output: -5 V (min)/-5.4 V (TYP)
• Receiver: Input voltage range: -15 V(min.)　~ +15V(max.)
• RS-232C communication method: asynchronous communication
• RS-232C Communication Parameters:
• Data bit length: 7/8
• Stop bit: 1/2
• Parity: None/Even/Odd
• Flow control: None, RTS/CTS, DTR/DSR, XON/XOFF
• RS-232C communication speed: 1200/2400/4800/9600/19200/38400/57600/115200 bps
• Transmission Range: RS-232C/15 m
• Power Supply Voltage: 5 VDC (AC Adapter Used)/37 VDC -57 VDC (PoE Receiving)
• Power consumption: PoE receiving Class1 1.1 W (max.)
• Operating environment: Temperature: 0~55 F, Humidity: 20~80% (noncondensing)
• Software:
• RS-ET62 ConfigTool: Configure Ethernet connection settings.　Configure the serial port settings.
• COM Emulation Driver (RATOC VSP): Assigning the product to a virtual COM port
• Communication sample program (VC++2008): RS-232C transmission and reception (COM mode/Socket mode) Source code attached
• Supported OS: Windows 11/10 * 64 bit only
• Package Contents: Product, Warranty
• Housing Material: ABS Resin
• Dimensions: 100 (L) x 67 (W) x 23 (H) mm
• Body Weight: Approx. 230 g
• Warranty 1 year
