• Representative Product Number; Compatible with RS tube terminals such as 119-160 119-160.
• RS PRO Hydraulic Crimping Tools
• RS PRO provides hydraulic crimping tools designed for industrial cable assembly applications such as automotive battery cables. This tool is useful and provides very useful features for applications that cannot be met with conventional crimping tools. This compact hand-held tool has the advantage of a spring-loaded handle and a 180 ° swivel head that allows die selection to proceed with only one hand, allowing the cable and connector to be restrained with the other hand that is free.
• Features and Benefits: 180 ° Rotary Head Die Set Included Safety Valve Built-in Pressure Relief Lever Shaped Plastic Carrying Case Enclosed Cable Range: 6-185 mm ^2 Crimping Force: 50 kN Rated Operating Pressure: 600 bar (8600 psi)
• Product Description: RS Pro Hydraulic Crimping Tool Die Set: 6 mm ^2, 25 mm ^2, 35 mm ^2, 50 mm ^2, 70 mm ^2, 95 mm ^2, 120 mm ^2, 150 mm ^2, 185 mm ^2 Plastic Case
• RS Pro Die Set (Sold Separately)
• RS Part Number:; 624-1358 624-1358,; 624-1308 624-1308,; 624-1336 624-1336,; 624-1320 624-1320 Typical Use
• Maintenance and Repair Electrical Equipment Cable Assembly Frequently Asked Questions: Is it easy to use This kit may seem difficult at first, but it is very easy to use. When in use, prepare the cable, slide it into the connector, select and insert the required die, and insert the cable and connector. Hold the cable in place with one hand and press the handle until the crimping tool begins to bite, then increase the pressure with both hands to complete the union when you feel resistance.　Please tell me how to maintain the product.　Moving parts should be lubricated regularly.　If the tool is exposed to dirt, it is recommended to lubricate * at least every 10,000 times.　Importance of high-quality crimping When a crimping tool is used for a terminal, two crimping operations are performed simultaneously. One is the electrical connection between the conductor and the terminal. The other is insulation crimping, which provides strain relief against vibration and tension. It is important that the electrical connection is airtight with no gaps between the strand and the terminal. The presence of voids can cause corrosion, resistance and heating, and damage electrical connections. The use of good quality crimping tools allows for fully airtight crimping and prevents future degradation of electrical connections and insulation.
