产品详细内容
产品型号: 64-8202-52
产品品牌: Diatrend Corporation
功能
- Industrial Ethernet switching hub with excellent environmental resistance and durability
- Support for PoE power supply
- SFP port included
- Conversion between optical signal and wired LAN is possible.
规格
- Ethernet Ports: 5
- 4 PoE ports
- Number of SFP ports: 1
- Transmission speed: 1000Mbps
- Network: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.3z, IEEE802.3af, IEEE802.3 at
- Interfaces: 10Base-T/100Base-TX/1000Base-T/100Base-FX/1000Base-X
- Power: 12~36 VDC (redundant power) (reverse polarity protection)
- Maximum power consumption: 10 W without PoE/145 W with PoE
- Operating temperature range: -40~65°C
- Material (Case): IP30 Steel
- PoE power supply system: Alternative-A(Data Line Usage 1, 2, 3, 6)
- PoE Power Supply: Port 1~4:30 W (IEEE802.3af/at compliant); 4 ports total: 12 VDC: 60 W; 24 VDC: 110 W; 36 VDC: 110 W
- Mounting Method: DIN Rail Mounting
- External Dimensions (mm): W55 x D110 x H140
