功能

• Optical fiber collimator housing.
• By combining optical fiber collimating lenses (FCL), the light of the FC connector fiber can be made into a collimated beam.
• The housing contains a mount that allows you to fix the collimator lens and change the focal position of the lens.
• The range of motion of the mount extends over the entire length of the inner cylinder of the housing, so a single device can accommodate collimated lenses of short to medium focal lengths.
• A total of 4 types can be selected: 2 types for PC polishing optical fibers and 2 types for APC (angled PC) polishing optical fibers, and 2 types for small diameter collimated beams (FC-12.7) and medium diameter collimated beams (FC-25.4).
• Holders are available to fix the housing and adjust the angle of the collimated beam.
• The FC-12.7 (PC/APC) has a dedicated optical fiber collimator holder (FHG-12.7).
• FC-25.4 (PC/APC) can be used with various mirror holders for φ25.4 mm mirrors.
• A special spanner (FCS) is available that allows you to adjust the position of the collimator lens while observing the collimator beam.
• * The optical fiber collimator housing does not come with a collimator lens.
• * Please purchase collimated lens (FCL) as well.
• * If the FC-12.7 (PC/APC) is attached to the kinematic mirror holder (MHG-MP12.7 NL), it may not be possible to attach or detach the connector.
