功能

• UL, CSA, ENEC
• 1 pole/2 pole switches have separately sold anti-mattress PVC covers. each stock number; 133-6287 133-6287 and; See 134 0400 134 0400.　Stock Number; The 607-7343 607-7343 has a dust cover.　One pole/two pole white type is also available. each stock number; 741 0918 741 0918 and; See 741 0864 741 0864.　For temporary expressions, the temporary state is expressed in parentheses: (on) -off- (on).　Presented current ratings and expected life are nominal. See the datasheet for more information.
• Marquardt 1800 Series Locker Switch
• Marquardt 1800 Series 1 Pole/2 Pole Locker Switch.　The long-life 1800 rocker switch is ideal for use with Class II equipment and is available in non-illuminated, red, amber or green 230 Vac neon actuator full illumination, white or black body color, and various wear resistance marks on the rocker switch actuator.　The contact is silver and the switching format is SPNO, SPST, SPDT, DPNO, DPST, or DPDT. It has 2/3-step switching, on/off, center off, and latch/temporary action contact switching.　The surface finish is matted silk, and when fitted into a 0.75 mm to 3 mm thick panel cutout, it is firmly fixed by the fixing rib of the switch housing.　A separately sold transparent PVC cover is used to protect against dust and water, and the rocker switch actuator is rated IP64.
• High rated current: up to 12 A High inrush current (capacitive): up to 50 A, stock number; 741 0855 741 0855 and; 607-7365 607-7365 has a maximum contact distance of 70 A: not less than 3 mm (contact distance of the 3-stage switching center-off type is less than 3 mm) Contact resistance:; 100 mΩ Insulation resistance: >100 MΩ Use of substrate terminal, solder tag or 4.8 mm faston/quick connect tab terminal for electrical connection Flame retardant rating: UL 94 V-2
