功能

• Spacial S3D Wall Box with Chassis Plate
• The Schneider Electric Spacial S3D steel wall-mounted enclosure features a one-piece folding/welding body, twice the plate thickness and a grooved front profile.
• Spacial S3D Series: Door with perforated rail (Drill diameter 4.2 mm at 25 mm pitch): (Enclosures with an exterior height of 400 mm or more must have 2 vertical rails, and enclosures with an exterior width of 800 mm or more must have 2 horizontal rails.)
• Features and benefits: Dustproof and resistant to strong fresh water and seawater jets in the enclosure IP66 protectionIK 10 rated external mechanical impact resistance (resists 5 kg objects falling from a height of 20 cm) Facilitates drilling and ensures maximum accessCable ground plate with grid patternHighly UV resistant aluminium hinged door removable, flipped to left/right openDoor has a maximum opening of 120 ° Wall mounted bracket fixed from the outside 2 x thicknessDoor with 20 mm foldback for greater stiffnessPolyurethane door seal included handles 2 functions as a tool to remove operating keys and stud protective caps
