产品详细内容
产品型号: 63-6995-45
产品品牌: Festo
功能
- NPQH Push-In Fittings - Female Screw
- The Festo NPQH series push-in connectors are designed for easy tube connection and provide a reliable seal. The compact design is ideal for pneumatic applications with temperatures up to 150 °C and pressures up to 20 bar. The NPQH series is an all-metal push-in joint made of brass chemically plated with nickel and is safe for use in the food industry. Features high corrosion resistance (CRC3) and chemical resistance.
- Features and Advantages: Quick and easy tube insertion
- Made of metal
- High heat resistance
- Detergent resistance
- FDA compliant
- High rated pressure
规格
- 数量:1袋 (10个)
- 连接样式:Threded-to-Tube
- 连接器A:G 1/8
- 连接器B:推入8mm
- 连接器A-性别:女
- 制造商系列:NPQH
- 安装类型:内联
- 主体材质:黄铜
- 最大工作压力:20 bar
- 最高工作温度:+150°C
- 最低工作温度:0°C
- 耐化学药品:是
- 食物等级:是
- 代码号:125-9610
