产品详细内容
产品型号: 63-6856-07
产品品牌: XP Power
功能
- XP Power-VCP24 Series Switch Mode Power Supply
- With a 24 W power supply, the XP Power VCP24 Series is a low-cost, board-mounted power solution for a wide variety of applications. The VCP24 series; It provides an output voltage of 5 to 15 V with a very low input power of 0.3 W. This series is designed to comply with the latest environmental laws and regulations. Because of its low profile, this series offers a wide range of small, reliable power supplies that are Medical/ITE certified.
- Features & Benefits: IT/Healthcare certified. Cost-effective solution. Substrate mounting class II structure. The output voltage is 5 to 24 V. The unloaded input power is; 0.3 W.
规格
- Quantity: 1 piece
- Output Voltage: 24 V dc
- Output Current: 1A
- Rating Power: 24 W
- Number of outputs: 1
- Input Voltage: 90 to 264 V ac
- Mounting Type: Chassis Mount
- Package Type: Open Frame
- Length: 73.8 mm
- Width: 41.6 mm
- Depth: 21 mm
- Weight: 75 g
- Efficiency: 82%
- Maximum temperature: + 70 degrees C
- Medical standards certification: Yes
- RoHS compliance status: Compliance
- Securities Code: 122 -7571
