产品详细内容
产品型号: 63-6849-72
产品品牌: XP Power
功能
- XP Power-IH Series Insulated DC-DC Converter
- The IH series of XP Power is a reliable dual-output 2W insulated DC-DC converter. The breakdown voltage is 1000 V dc and is provided in industry-standard SIP or DIP packages. Each of these compact DC-DC converters has a wide operating temperature of -40 to +85 °C and a maximum efficiency of 82%.
- 2 W Insulation DC-DC Converter 1000 V dc Insulation Voltage Dual Output Operating Temperature Range: -40 → +85 °C Industry Standard SIP/DIP Packaging Maximum Efficiency: 82%
规格
- Quantity: 1 piece
- Output Voltage: ± 5V dc
- Input voltage range: 4.5 to 5.5 V dc
- Input voltage nominal: 5V dc
- insulation Voltage: 1 kV dc
- Rating Power: 2W
- Output current: ± 200 mA
- Mounting type: through hole
- Number of outputs: 2
- Efficiency: 72%
- Packages: SIP
- Road regulation: ± 10%
- Maximum temperature: + 85 degrees C
- Length: 19.5 mm
- RoHS compliance status: Compliance
- Securities Code: 122 -6918
