产品详细内容
产品型号: 63-6844-28
产品品牌: XP Power
功能
- XP Power-ITV Series Insulated DC-DC Converter
- The XP Power ITV series DC-DC converter is a rugged and reliable product that can be used in a variety of applications. The ITV series is a single-output converter that uses the SIP package.
- Features and benefits: Single output and dual output. SIP package. Industry standard pin alignment. MTBF >3500 hours Wide operating temperature range: -40 °C → +105 °C, at full load: 95 °C (ambient temperature).
规格
- Quantity: 1 piece
- Output Voltage: 5V dc
- Input voltage range: 4.5 to 5.5 V dc
- Input voltage nominal: 5V dc
- insulation Voltage: 3 kV dc
- Rating Power: 1W
- Output current: 200 mA
- Mounting type: through hole
- Number of outputs: 1
- Efficiency: 80%
- Packages: SIP
- Minimum temperature: -40 degrees C
- Maximum temperature: + 105 degrees C
- Length: 19.5 mm
- RoHS compliance status: Compliance
- Securities Code: 122 -6055
