产品详细内容
产品型号: 63-6823-05
产品品牌: Hirose
功能
- DH Series Plug Unit
- This DH series connector from Hirose is an impedance-controlled interface plug connector for high-speed transmission. Equipped with solder contacts and designed with a contact engagement pitch interval of 1 mm.
- Features and Advantages: Rated current: 0.5 A Rated voltage: 125 V ac Operating temperature range: -25 → +85°C Maximum number of insertions and displacements: 1000
规格
- Quantity: 1 Tray (50 Pieces)
- Number of contacts: 37
- Male/Female: Female
- Terminal types: solder
- Poles: 37
- Rated current: 500 mA
- Rated voltage: 125 V ac
- Pitch: 1 mm
- Body Orientation: Straight
- Series: DH
- Housing Material: PA
- Length: 24.8 mm
- Width: 15.7 mm
- Depth: 9.55 mm
- Dimensions: 24.8 x 15.7 x 9.55 mm
- Operating temperature Min: -25°C
- RoHS Compliance Status: Compliance
- Securities Code: 122-1686
