功能

• Hirose FunctionMAX FX10 0.5mm Stacking Connectors without Grounding Plate
• FunctionMAX FX10 0.5 mm high-speed 15+Gbit/s SMT board to board stacking connectors designed to meet requirements of the industrial market with maximum functionality
• The FunctionMAX FX10 connector provides an electrical interface for the OIF 100G Long-Haul DWDM Transmission Module (MSA-100GLH)
• Metal mounting fittings at either end of the connector help to increase PCB retention and provide extra solder weld strength
• Guideposts are also featured that help to align and secure the connector to the PCB
• Features and Benefits
• Compact 0.5 mm pitch ideal for use in high density applications High speed performance 15+Gbit/s Metal fittings for increased PCB retention Guideposts for accurate PCB alignment and retention Stacking height of 4mm to 13mm
• Applications
• With a compact 0.5 mm pitch, the FunctionMAX FX10 stacking connector is ideal for high-density substrate applications. Other applications include medical devices, industrial controllers, industrial motors, servers, measurement equipment, smart meters, base station transceivers, and PLCs.
• The FunctionMAX Brand
• FunctionMAX board to board connectors are designed to meet the needs of advancing technologies within the industrial market and offer high performance and maximum functionality
• The FunctionMAX range includes connectors with a floating design and connectors with a high-speed transmission rate
• The high transmission connectors have a design based on a differential transmission system and offer high-speed signals and excellent resistance to noise
• The FunctionMAX range of board to board connectors offer superior performance in diverse environments.
