规格

• Projection Distance: 400 mm Fixed
• Pattern Shape: Spot Approx. φ1mm
• Wavelength: 520 nm±10 nm
• Optical output: 1 mW or less CLASS2
• Optical axis accuracy: +/- 5°
• Average life: 10,000 hours/room temperature continuous
• Power supply voltage and current: 6.0~7.0, 50mAmax
• Connection method: twisted pair cable blue/black
• Weight: about 20 g
• Operating temperature range: -10~50°C (not to freeze)
• Operating Humidity Range: 20~85%RH (non-condensing)
• Cable length: 600 mm
• Tip Size: φ12 x 41 mm
