产品详细内容
产品型号: 67-5823-85
产品品牌: CHUO PRECISION INDUSTRIAL Co., Ltd.
功能
- The polarizer and wavelength plate are fixed and used to adjust the polarization plane.
- Loosen the coarse clamp screw for 360° movement. Tighten the coarse clamp screw for fine adjustment with the micrometer head.
- Since the scale ring moves independently, 0 point can be set at any angle position.
- For incorporating Gram-Thomson prisms, polarizing prisms, polarizing plates, small cameras, etc.
规格
- Type: Polarizing element holder
- Applicable Size (mm): Φ30, t1~13
- Effective diameter (mm): phi 27
- Adjustment range (°): coarse motion 360, fine motion ±4
- Percent (′): Vernier Reading 5
- Holder Center Height (mm): 33.9
- Mounting shaft (mm): phi 12, length 60
- Mass (kg): 0.15
相关产品推荐
您可能还对以下产品感兴趣
生命科学/分析仪器
61-0380-01 ［已停用］用于合成的4-甲基苯甲酸841700 100G 8.41700.0100
