产品详细内容
产品型号: 63-6787-64
产品品牌: 3M Company
功能
- UL Certified
- These cables are not intended as power cables or cables for direct connection to the main power source of the equipment.
- Shielded Round Type 1.27 mm Pitch Ribbon Cable - Type 3659
- ・ Stranded Tin-plated Copper Conductor Insulated with Black PVC ・ Aluminized Polyester Tape and Tin-plated Copper Blade Allows Large Termination by Repeated Double Shielding, Splitting/Joining • UL AWM Standard 20267
规格
- 数量:1卷 (30米)
- 杆数:26
- 宽度:31.8 mm
- 间距:1.27 mm
- 卷轴长度:30 m
- 允许电压:300 V
- 容量:90.88 pF/m
- 特征阻抗:106欧姆
- 工作温度最小值:-20摄氏度
- 工作温度最大值:+80度C
- 核心字符串:7/36
- RoHS合规性状态:合规性
- 证券代码:120 -9129
