功能

• EMC - meets the requirements for on and off-road applications covered by directives 95/54 and 89/336
• Disconnect and leave for 5 minutes before touching
• Lens and bulb
• DIN or Flexi DIN beacons can only be mounted using the DIN mounting stem, which is available separately (stock no
• ; 235-613 235-613 )
• Xenon Beacons
• These small profile xenon beacons have low power consumption and are ideal for 12/24 V applications
• They are sealed units offering IP56 protection and are supplied with amber, red, blue or green lenses
• Fitting Information
• Ensure that all beacons are fitted to the vehicle with the base parallel to the ground
• For the magnetic beacons, ensure that the surface is clean before fixing to provide a solid contact (maximum safe speed is 70 mph)
• The DIN mount beacons have a mating plug in the base for electrical connection and a clamp to secure them to the DIN Mounting Stem
• The clamp enables the beacon to be securely fastened when in use and then loosened for removal
• The DIN Mounting Stem is mounted through a hole and held in place with the two clamp nuts supplied
• It has an electrical socket mounted in the top which can be unscrewed and wires attached
• Features and Benefits
• Low power consumption IP56 rated, sealed against dust and moisture Reverse polarity protection Flash rate 75 FPM Magnetic versions are rated to 70 mph
• Application Information
• These xenon beacons are suitable for mounting on utility vehicles, agricultural vehicles, construction vehicles and fleet vehicles.
