产品详细内容
产品型号: 63-5052-34
产品品牌: 3M Company
功能
- The pitch interval shown is the pitch interval of the PC tail.
- Straight Panel Mounting Through Hole Receptacle 102 Series with Screw Lock
- This 3M Mini D Ribbon (MDR) 102 Series PCB Shielded Receptacle has M2.5 or M2.6 Lockdown Screws.
- Designed with a latch interface for stable connector connections.
- Kanai Party: 101XX-6000 Series Plug, Representative Product Number; Refer to 163-3285 163-3285 Contact: 101XX-3000 Series Plug, Representative Part Number; Refer to 515-7476 515-7476. N 102xx-xxxxxx: Heat Resistant PCT Insulator x102xx-xx 0 xxx: M2.6 Panel and Screw Lock x102xx-xx 1 xxx: M2.5 Panel and Screw Lock x102xx-xxxxxxP C: 0.76 μm Gold Plated on Contact, with Gold Plated on Tail x102xx-xxxxP L: 0.2 μm Gold Plated on Contact, with Gold Flash Plated and Lubricant on Tail
规格
- 数量:1件
- 联系人数量:26
- 性别:女
- 身体方向:直
- 安装类型:通孔
- 间距:1.27毫米
- 当前评级:1A
- 房屋材料:玻璃纤维增强PET
- 长度:37.2mm
- 宽度:11mm
- 深度:9.1毫米
- 尺寸:37.2 x 11 x 9.1mm
- 最低工作温度:-20°C
- 代码号:749-4856
