规格

• Implementation: Lead
• Digits: Single digits
• Colour of light emitted: green
• Common: Anode
• Size: 13.0 mm x 10.0 mm x 7.0 mm
• Text height: 9.9 mm
• Peak wavelength (typ): 568 nm
• Forward current IF: 50 mA
• Reverse voltage VR: 5 V
• Allowable loss Po: 100 mW
• Operating temperature: -40 C to + 80 C
• Storage temperature: -40 degrees C to + 80 degrees C
• Forward voltage VF/standard: 2.2 V
• Forward voltage VF Max: 2.6 V
• Forward voltage VF condition IF: 20 mA
• Reverse current IR/max: 100 microA
• Reverse current IR/condition VR: 5 V
• Brightness/Min: 7 mcd
• Brightness/Normal: 15 mcd
• Brightness/Condition IF: 20 mA
