规格

• Color: Navy Blue
• Cable length: 0.5 m
• Connector Shape: RJ-45 Shielded Connector (with Cover to Prevent Folding of Claws)
• Cable structure: Stranded (26AWG), ScTP, Straight
• Cable diameter: 6.8 mm
• color wires: TIA/EIA-568B
• Supported transmission bands: Category 6A (10GBASE-T), Category 6 (1000BASE-TX), Category 5e (1000BASE-T), Category 5 (100BASE-TX), Category 3 (10BASE-T) compliant
• 10Gbps
• Frequency response: 500 MHz
• Inspection: 100% continuity inspection, 100% fluke inspection, 100% low resistance precision measurement
• *Due to the structure of the plug, some transmission characteristics (FLUKE NEXT) may not meet the conventional values due to soldering, but we have not confirmed any deterioration in actual communication performance.
• Number of Cable Cores: 8 Cores (4P)
• Cable Cover: Oil-Resistant, Temperature-Resistant PUR (PUR Temperature-Resistant -40 °C ~105 °C)
• connections in connectors: auto-soldering
• Temperature range: – 40~105°C
• Flame Retardant: Flame Retardant Material Used
• Flexibility: 5 million cable bear tests
