规格

• Materials: B30203: Aluminum Alloy
• Use Environment: 10~40 °C/20~ 80% (non-condensing)
• Input Power Requirements: B30205: 90~240 VAC 50/60Hz
• Electrical power consumption: 57VA
• Compatible Container (Supported Devices): Well Plate, φ35 mm Dish,
• Single Type Slide Glass
• Weight: 8.6 kg
• Direction of travel: B30203: X (A) Y (B) axis 2 direction
• Travel Range: B30203: X-Axis ±55 mm, Y-Axis ±37.5 mm
• Resolution Minimum Step Size (Resolution): B30203:
• Full step (1/1): 2 μm (mechanical),
• Half Step (1/2): 1 μm (When BMC-M752 is Used)
• Repeatability: B30203:2 μm*1
• Leadscrew Pitch: B30203:1 mm
• Motor Type (Motor Tyoe): B30203:5 Phase Stepping Motor (0.75 A/Phase)
• Full step (1/1): 0.72 degree stepper (mechanical),
• Half Step (1/2): 0.36 degree stepper (when BMC-M752 is used)
• Control Method: B30205: Open loop control
• Maximum Acceleration Time: B30205:1~1,000 ms
• Maximum Velocity:
• Full step (1/1):30mm/s (15,000pps),
• Half Step (1/2):30mm/s (30,000pps)
• Number of Controlled Axes: B30205:2 Axes (Standard Step Driver)
• Communication Interface: B30205: RS-232C
