功能

• Adapter for fixing the laser beam expander to a 5-axis lens holder (ALHN-50-5RO) with a centering mechanism.
• Can be used with all BE/LBED/LBE beam expanders.
• Other than the 5 axis lens holder, it can be attached to various mirror holders that can fix elements of φ50.
• If you attach the rod directly to the adapter, it can be used as a fixed beam expander holder.
• The adapter can also be fixed to the mirror holder (MHG-MP50 NL) or the cross-motion holder (TAT-16RO).
• Refer to the 5 axis lens holder (ALHN-50-5RO) for detailed specifications of the centering mechanism.
• An adapter that is fixed to the He-Ne laser light source is provided as an accessory to the beam expander (BE, LBED).
• See Laser Beam Expander for details.
• * When attaching the beam expander to the 5 axis lens holder (ALHN-5RO), secure it so that the beam expander is attached to the side opposite to the screw ring.
• * Does not attach in the opposite direction.
• * When the beam expander is fixed to the movable holder other than the 5-axis lens holder, the movable mechanism of the holder may not work properly depending on the combination.
