产品详细内容
产品型号: 61-6981-12
产品品牌: SIGMAKOKI CO., LTD.
功能
- This straight moving stage has the same structure and performance as the steel stage TSD series and is suitable for clean room and vacuum applications.
- All of them are made of stainless steel, so they have excellent corrosion resistance.
- Both the stage body and the micrometer head use high vacuum grease (YVAC2).
- The TSDS series is suitable for clean room and vacuum applications.
- It is also ideal for use in airtight, narrow spaces that dislike outgassing.
规格
- [>XZ轴不锈钢工作台 (垂直) 工作台尺寸□ 25/□ 40/□ 60/□ 65 mm< 通用规格]
- 移动指南:球指南
- 主要材料:不锈钢
- 表面处理:否
- 【个别规格】
- 表格曲面大小:25 x 25 mm
- 微操作位置:中心
- 移动量:X轴:±3mmZ轴:±3mm
- 移动量/1旋转:0.5公厘
- 微米最小读数:0.01mm
- 承受负载:14.7N (1.5kgf)
- 移动精度/直线度:1μm
- 允许力矩负载/螺距:2.2N·m
- 允许的力矩负载/滚动:2.1N·m
- 力矩刚度/螺距:5.1′′/N·cm
- 质量:0.17公斤
- 符合RoHS标准的产品
