• Hirose Electric HR10A Series Push-Pull Round Connector
• We offer a wide range of high-performance plugs, receptacles and jacks for the HR10A series from Hirose Electric. Micro round connectors are compact, durable, and lightweight. The compact design of the HR10A connector makes it an ideal solution for high-density applications where space is limited. A simple push-pull mechanism allows for a single, smooth connection and removal. The 5-key polarization system for accurate alignment ensures engagement and correct positioning even during blind mating.
• For Cable-panel applications, the Cable mounting plug with male contact is mated to the panel mounting receptacle with female contact. For Cable-to-cable (in-line) applications, the Cable mounting plug with male contact is mated to the Cable mounting jack with female contact. For the appropriate contact, the part number in the case of a female; 764-4547 764-4547 and; 166-4964 166-4964 for male contact; 764-4543 764-4543 and; Refer to 166-4963 166-4963.
• Two types of manual crimping tools are available. Part Number; 772-7112 772-7112.; See 772-7115 772-7115
• Features and Advantages: 5-Key Polarized Single-Action Push-Pull Coupling Mechanism for Accurate Alignment High-Density Mounting Compact Lightweight Design Solder and Terminals for Space Saving
• Applications: The HR10A series of connectors are ideal for use in commercial and industrial electronic and electrical small equipment. Primary use:
• Computers/Peripherals Audio Equipment Video Equipment Portable Wireless Equipment Measurement Equipment Instrumentation
• Frequently asked questions: Q: How robust are the connectors?　A: The HR10A connector is manufactured from durable engineering materials. Robust and reliable product.
• Q - Do you have accessories?
• A - A variety of circular dust caps can be used to provide additional protection against dust and moisture. The dust cap protects the connector when not in use.
• ; 764-5063 764-5063: Dust Cap for Shell Size 7 Pole Connector; 764-5060 764-5060: Dust Cap for Shell Size 10 Pole Connector; 764-5067 764-5067: Dust Cap for Shell Size 13 Pole Connector
