规格

• In order to operate this radio, you need to have a 4th class amateur radio operator qualification or higher.
• [General Specifications]
• Frequency range transmission: 430~440 MHz
• Receive: 400~470 MHz (excluding some frequencies)
• Radio types F2D, F3E
• Antenna Impedance 50 Ω
• Voltage Range: 6.0~9.0 VDC (Standard Voltage: 7.4 VDC)
• Operating temperature range -20°C to +60°C
• -10°C~+50°C with -46 L PB
• Frequency stability ±2.5ppm
• Battery life
• (Hi/Mid/Low) * When using PB-46 L: Approx. 7/Approx. 10/Approx. 12 hours
• When BT-16 is used * *: Approx. 6/Approx. 8/Approx. 10 hours
• Dimensions (W x H x D)
• Without Projections When PB-46L is Installed: 54 x 111.7 x 27.2 mm
• With BT -16: 54 x 111.7 x 29 mm
• Weight: When the main body + -46 L PB is installed: Approx. 228 g
• Body +BT -16: Approx. 178 g (without batteries)
• ■transmission part
• Transmit Output Hi: 5W
• Hi (when using BT -16): Approx. 3.5 W
• Mid:2W
• Low:1W
• modulation system reactance modulation
• Maximum frequency deviation within ±5 kHz
• Transmit spurious less than -6dB
• Modulation distortion 5% or less
• Microphone impedance 2 kΩ
• ■receiving part
• receiving system double super heterodyne system
• Intermediate frequency 1st IF: 38.85 MHz
• 2nd IF:450kHz
• Sensitivity (12dB SINAD) 0.18 μV or less
• Squelch sensitivity 0.13 μV or less
• Selectivity -6dB: 10 kHz or higher
• -50dB: 28 kHz or lower
• Low-frequency output (8 Ω, 10% strain)400 mW or more at 7.4 V
• Measurement shall be conducted according to the measurement method specified by JAIA (in amateur radio band).
• Measurement conditions: Send 6 seconds, Receive 6 seconds, Standby 48 seconds
• ** Due to the characteristics of alkaline batteries, the displayed values may not be displayed depending on the time of use when the battery is not low power. We recommend that you use the low power setting.
