规格

• Target gas: Hydrogen cyanide
• Detection range (ppm): 0-15.0
• 1 digit (ppm): 0.1
• Alarm settings: 1st 5.0ppm, 2nd 10.0ppm, STEL 4.7ppm
• Gas alarm: 2-stage alarm, TWA, STEL, OVER alarm
• Failure alarm: System error, sensor error, battery voltage drop, calibration failure, flow drop
• Others: Panic warning and mandown warning
• display of alarm
• Gas alarm: lamp blinks, buzzer continuously modulated sound, gas concentration display and alarm content blinks, vibration
• At the time of failure warning: lamp blinks, buzzer is intermittent, failure details display
• Others: Lamp blinks, buzzer continuously modulated sound
• Buzzer volume (dB): 95dB (A) or more at 30 cm (when protect cover is attached)
• Sampling Type: Pump Suction Type
• Suction Flow Rate: 0.45 L/min or More (Open Flow Rate)
• displays: LCD digital (full-dot display)
• Display language: Japanese, English, Spanish, Portuguese, German, Italian, Russian, Korean
• Power supply: Lithium-ion battery unit
• Continuous Use: Approximately 14 hours (25°C, fully charged, no alarm, no lighting)
• Operating temperature range (°C): -20 to +50 (No sudden change)
• Operating humidity range: 95%RH or less (no condensation)
• External Dimensions (mm): Approx. 70 (W) x 201 (H) x 54 (D) (Excluding Protrusions)
• Mass (g): about 500
• Protection Class: IP67
• Explosion-Proof Structure: Intrinsically Safe Explosion-Proof Structure
• Explosion-Proof Class: Ex ia IIC T4X
• Functions: LCD backlight, data logger, peak value display, log data display, multi-language display, inverted display, LED light
