65-3535-84 ［Out of stock］Pipe Outer Surface Type Temperature Sensor Model 1811 with ISO Documents -50~100°C Pincer Type E Type 1811E-TS1-ASP
产品描述
产品型号: 65-3535-84产品品牌: ANRITSU METER CO., LTD. 功能 Model […]
联系我们
产品详细内容
产品型号: 65-3535-84
产品品牌: ANRITSU METER CO., LTD.
功能
- Model 1811 is a temperature sensor that measures across a pipe (applicable pipe diameter φ6~25 mm).
- You can measure the surface temperature of the pipe by pinching the pipe.
- [Application] Measurement of Pipe Surface Temperature
规格
- Material: Grip Material/Black Phenol Resin
- Operating temperature range (°C): -50~100
- Tolerance at 0~100 deg. C (deg. C): ±2.5
- Response Time (sec): 2
- Shape: Scissors Type
- Thermocouple Type: E Type
- Code Type: Standard Code
- Cord length (m): 1
- Plug Shape: Standard Plug
- Calibration temperature point: 100°C
- Document content: Inspection report, calibration certificate, traceability system diagram
