65-3535-76 ［Out of stock］Micro Surface (Plug Type) Temperature Sensor Model 343 with ISO Documents -50~250°C 30° E Type 343E-TC1-ASP
产品描述
产品型号: 65-3535-76产品品牌: ANRITSU METER CO., LTD. 功能 Model […]
联系我们
产品详细内容
产品型号: 65-3535-76
产品品牌: ANRITSU METER CO., LTD.
功能
- Model 310/343 is a temperature sensor for micro surface (plug in type) which can measure the side of inserted gap.
- [Application] Measurement of temperature distribution of IC packages, etc.
- Surface temperature measurement of printed circuit boards, etc.
- surface temperature measurement of the cooler fin
- Other measurements of surface temperature of electronic components
规格
- Material: Guard Material/Sumika Super, Pipe Material/Stainless Steel (SUS304), Grip Material/Black Phenol Resin
- Operating temperature range (°C): -50~250
- Tolerance at 0~200 deg. C (deg. C): ±2.5
- Response Time (sec): 0.5
- Durability: 10,000 cycles or more
- Pipe Shape: 30°
- Thermocouple Type: E Type
- Code Type: Standard Code
- Cord length (m): 1
- Plug Shape: Standard Plug
- Calibration Temperature Point: 100, 200°C
- Document content: Inspection report, calibration certificate, traceability system diagram
