65-3534-27 ［Out of stock］Screw Temperature Sensor SC Series with ISO Document Set -50~300°C Screw Diameter: M2 Glass Fiber E-Type SC-22E-GW1-ANP
产品描述
产品型号: 65-3534-27产品品牌: ANRITSU METER CO., LTD. 功能 The SC […]
联系我们
产品详细内容
产品型号: 65-3534-27
产品品牌: ANRITSU METER CO., LTD.
功能
- The SC series is a temperature sensor with a screw fastening structure on the tip.
- [Application] Temperature control and temperature measurement of metal plate by heating using cartridge heater, etc.
规格
- Material: Screw Fastener Material/Stainless Steel
- Operating temperature range (°C): -50~300
- Tolerance at – 40~150 deg. C (deg. C): ±3.5
- Response Time (sec): 5
- Corresponding Screw Diameter: M2
- Thermocouple Type: E Type
- Cord length (m): 1
- Cord Outer Diameter (mm): 1.2 x 1.7
- Coating Material: Glass Fiber
- Heat-resistant Temperature (°C): 300
- Plug Shape: Mini Plug
- Calibration Temperature Point: 100, 200, 300°C
- Document content: Inspection report, calibration certificate, traceability system diagram
