产品详细内容
产品型号: 61-0173-70
产品品牌: Honda Electronics Co., Ltd.
功能
- Installation, wiring, and operation costs can be reduced by adopting a two-wire system.
- The body is fully chemical resistant resin (PP).
- High resolution of 1mm for both display resolution and internal resolution.
- Compact and lightweight body integrating sensor part and control part.
- Main applications and examples of use Liquid level control of tanks, etc. Management of treated water levels in sewer pipes. Measurement of water levels in lakes, swamps, and rivers.
规格
- 频道数:1
- 频率:50kHz
- 测量目标:液体
- 距离测量范围:0.3-6.5米
- 解析度:度量:1公厘:显示:1公厘
- 准确度:±0.25%F.S. (±1.63公分)
- 资料更新周期:1秒
- 传感器定向角 (声压角的一半) :14°
- 电源:电压:DC16-32V:耗电量:0.64W
- 显示器:4位数LCD
- 输出:4-20 mA目前输出:解析度:12位元(最大负载电阻500Ω:24V:双线系统)
- 环境温度范围:-20 -60°C
- 材料:PP (聚丙烯)
- 结构:相当于IP65 (打开盖子时:IP20当量)
- 外部尺寸:φ93×110 mm
- 配电缆线长度:10公尺
- 质量:350 g
- 安装螺丝:G2 (PF2)
