规格

• Controller: EXAR XR17V354IB176
• FIFO buffer: 2 x 256 bytes (S , Receive) x 2 ports
• Cable specifications: D-sub 44pi male to D-sub 9pin male x 2 ports (Approximately 60 cm, inch screws #4-40UNC)
• Number of ports: 2 ports
• Interface Specifications: PCI Express: 1 x 2.0 (Gen1)
• Communication speed: Up to 921.6kbps
• IRQ d: 1
• Maximum concurrent connections: 2
• Supply voltage: 3.3 VDC
• Current consumption: 110 mA (Max)
• Board Size: Approx. 90 (W) x 69 (H) mm * Excluding Slot Cover Portion and Protrusions
• Weight: Approx. 54 g * Excluding cable
• Weight (when packed): Approx. 270 g
• Operating temperature range: 0~55°C
• Operating humidity range: 10~90% (no condensation)
• Certification standards: VCCI Class B, RoHS Directive compliant (10 substances)
• Warranty Period: 1 Year Warranty
