63-1395-99 压力和防 搅拌器 B-200G
实验室仪器

63-1395-99 压力和防 搅拌器 B-200G

型号: 63-1395-99
品牌: TOKYO RIKAKIKAI CO., LTD.
分类: 实验室仪器

产品描述

产品型号: 63-1395-99产品品牌: TOKYO RIKAKIKAI CO., LTD. 功能 High […]

联系我们

咨询热线

18866622123

微信咨询

微信号: AHY97319570

微信二维码

产品详细内容

产品型号: 63-1395-99
产品品牌: TOKYO RIKAKIKAI CO., LTD.

功能

  • High torque, wide range of rotation speed, pressure-proof and explosion-proof type
  • A pressure-proof and explosion-proof motor approved by the Fire and Disaster Management Agency is used. - The pressure-proof and explosion-proof standard is compatible with d2G4 and can be used safely except for some substances such as carbon disulfide and acetylene.
  • The high power induction motor gear is decelerated, which results in low speed rotation.
  • It is designed to provide high torque over the entire speed range. Exhibits power in high-viscosity stirring experiments.

规格

  • 压力和防 底座参考:d2G4
  • 转速范围 (rpm) :7~1360/50 Hz,8~1640/60 Hz
  • 速度设定:20次变速 (通过换挡和切换4个拨盘)
  • 安全特性:夹头盖
  • 电机:压力和 炸概率200 W
  • 底座:500 x 340 mm
  • 搅拌棒外径/夹头截面:1~10/钻头夹头 (SUS)
  • 杰克行程:400 mm
  • 工作 温度范围:5~35摄氏度
  • 外形尺寸:机身175 (365) x 406 x 342 mm (机架高度815) /*内部尺寸 () 包括突起。
  • 质量:身体约。18公斤,杰克6.5公斤,基地7公斤
  • 电源输入。电源电压:2 A, 700 VA/AC 200 V,3相50/60 Hz
  • *性能测量在室温20摄氏度,额定电源电压和无负载。
  • *不包括电源线和插头。
  • *配件:1个搅拌棒(Phi 8 x 495 mm, SUS 304),搅拌刃:1个(扁平叶片涡轮,叶片直径φ50 mm, SUS 304)
  • 代码:121040
