• Description
• RFID(radio-frequency identification)is the wireless non-contact use of radio-frequency electromagnetic fields, for the purposes of identifying and tracking tags attached to objects. This is the ID-20LA, a very simple to use RFID reader module from ID Innovations. With a built in antenna, the only holdup is the 2mm pin spacing. Power the module, hold up a 125kHz card, and get a serial string output containing the unique ID of the card.
• Note:The new ID-20LA is essentially the same as the older ID-20, but has a lower input voltage.
• Features
• 2.8 - 5V supply
• 125kHz read frequency
• EM4001 64-bit RFID tag compatible
• 9600bps TTL and RS232 output
• Magnetic stripe emulation output
• Read range of 180mm
• 38x40x7mm
