规格

• Maximum power output: 76.8 W
• Input Voltage Range: 85 ~ 132 VAC/170 ~ 265 VAC (47 ~ 63 Hz) Input Automatic Switching
• Output voltage rating: 48 VDC
• Output maximum current: 1.6 A
• Operating temperature range: -10 degrees C to + 60 degrees C (-10 degrees C to + 50 degrees C ... 100%, + 60 degrees C ... 70%) (With Cover ...- 10 C to + 30 C: 100%, + 40 C: 80%, + 50 C: 60%)
• Efficiency (typ): 0.8
• Mass (g): 500
• Size (W x H x Dmm): 55 x 35 x 222
• Remarks: Molex connector, board type
• Peak output power is 120% compatible (ZWS 120 PPF is 200% compatible)
• LOW-COST!!
• Output variable volume standard equipment
• RoHS compliant
