规格

• Output Power: 15/7. 22 W
• Input voltage range: 85 ~ 265 VAC at 47 ~ 440 Hz, 110 ~ 330 VDC continuous input
• Output Voltage: 5 V +/- 1%/+ 12 V/-5 V
• Output current: 0.5 to 3/0 to 0.6/0 ~ 0.4 A
• Efficiency (typ): 0.72
• Operating temperature range: 0 degrees C to + 60 degrees C Natural air cooling 0 degrees C to + 40 degrees C: 17 W, 50 degrees C: 14 W, 60 degrees C: 10 W
• Dimensions: Approx. 128 x 60 x 26 (mm)
• Remarks:
• CE marking (Low Voltage Directive Compliant) CE marking by EN 60950 certification
• Wide input voltage range: 85 ~ 265 VAC continuous input
• Watt box design Within total output power, each output can be leveraged.
• Thin, 3-power 17 W to 50 W 3 models 9 models
• Isolation between CH1 (5 V) and +/- CH
