3-2361-01 超薄纸 (R) 垫片500 x 500 x 1.0 HS-1

型号: 3-2361-01

产品描述

产品型号: 3-2361-01 功能 It has excellent chemical resistance […]

联系我们

咨询热线

18866622123

微信咨询

微信号: AHY97319570

微信二维码

产品详细内容

产品型号: 3-2361-01

功能

  • It has excellent chemical resistance and can be used in all fluids except high-temperature and high-pressure fluorine gas, molten alkali metal, and polymerizable monomers (it can be used at pH0~ 14).
  • It blends easily and can be easily sealed even with a slight irregularity. It is also resistant to stress fluctuations and provides stable sealing for a long time.
  • With 100%PTFE, no impurities are eluted, and it has excellent heat resistance and sliding properties.

规格

  • 型号:HS-1
  • 尺寸 (公厘) :500 x 500 x 1.0
  • 材料:膨胀PTFE (PTFE 100%) (氟树脂)
  • 作业温度范围:-240 -315°C
  • 垫片系数 (m) :2.5
  • 小设计紧固压力 (y) :19.6N/mm2
  • 耐压:真空至20.6MPa
  • ※本产品不用于GMP管理下的直接接触 器械材料,食品,化妆品等的过程。*还有其他厚度的。请和 联系。*根据所需尺寸,可以进行切削加工 ( 大长度1500×1500 mm) 。

相关产品推荐

您可能还对以下产品感兴趣

64-2208-80 塑料外壳 (透明/3张) 1.016 mm EA440EJ-15
