规格

• Specifications: Meter Body Set
• Number of pieces: 1
• Measurements: pH/ORP/Ions/Temperature/Electrical conductivity/TDS/Salinity/Electrical resistivity
• Data memory count: 2000
• PC connection: Yes (USB communication cable required)
• Printer output: Yes (GLP, GMP ready)
• Power Supply: AC Adapter (100 ~ 240 VAC 50/60 Hz (Main Unit Power Supply: 7 VDC 0.7 W))
• External dimensions: 160 x 150 x 66 mm (excluding integrated stand)
• Weight: approximately 770 g
• Accessories: Electrode stand (FA -70 S), AC adapter
• *Sensors (pH electrode, electrical conductivity cell) are not included.
• Measurement items: pH
• Measuring range: pH 0.000 ~ 14.000
• Resolution: 0.01/0.001 pH
• Accuracy: +/- 0.005 pH +/- 1 digit
• Measurements: ORP
• Measuring range: +/- 2000.0 mV
• Resolution: 0.1 mV
• Accuracy: +/- 0.1 mV +/- 1 digit
• Measurements: Ions
• Measuring range: 0.000 ug/L to 9999 g/L mmol/L, mol/L, ppm, ppt (1000 minute rate), ug/L, mg/L, g/L
• Resolution: 4 digits (effective resolution: 0.1 mV)
• Accuracy: +/- 0.5% F.S, or +/- 0.2 mV, whichever is greater
• Measurements: Temperature
• Measuring range: 0.0 to + 100.0 degrees C (Display range/-30.0 to + 130.0 degrees C)
• Resolution: 0.1 degrees C
• Accuracy: +/- 0.5 degrees C
• Measurements: Electrical conductivity
• Measuring range: 0.000 ~ 2.000 S/cm
• Resolution: 4 significant digits (automatic range change)
• Accuracy: +/- 0.6% of each rangefull scale (18 mS/cm or more: 1.6% of full scale)
• Measurements: TDS
• Measuring range: 0.00 ~ 100.0 g/L (ppt)
• Resolution: 0.01 mg/L (ppm), 0.1 g/L (ppt)
• Accuracy: Greater of 0.5% or 0.1 mg/L
• Measurements: Salinity
• Measuring range: 0.0 ~ 100.0 ppt/0.00 ~ 10.00%
• Resolution: 0.1 ppt/0.01%
• Accuracy: Greater than 0.5% or 0.1 ppt
• Measurements: Electrical Resistivity
• Measuring range: 0.001 ~ 20.0 megohm/cm
• Resolution: 4 significant digits * However, 1.0 megohm/cm or more: 3 significant digits
• Accuracy: +/- 0.6% of full scale for each range * However, 1.8 megohms/cm or more: +/- 1.5% of full scale
