产品详细内容
产品型号: 63-3177-87
产品品牌: OMRON Corporation
功能
- In a normal relay, the contact state is determined by whether one coil is energized or not.
- This latching relay has two windings, set and reset, and the contact is set (ON) by energizing one of them, and reset (OFF) by energizing the other. The contact state is determined by which coil was energized just before, and the state is maintained even if energization is stopped.
规格
- 实现:印刷电路板
- 联系人配置:2 c
- 额定线圈/直流电压:12 V
- 接触节和额定负载DC:30 V, -2 A
- 接触区/额定负载交流电:125 V, -0.5 A
- 接触机制:横杆双胞胎
- 线圈额定电流:15 mA
- 线圈和线圈电阻:800Ω
- 设定线圈返回时的电感:0.6 H
- 线圈工作电感:0.45 H
- 复位线圈复位时的电感:0.45 H
- 线圈工作电感:0.6 H
- 线圈设定电压:70%或更低
- 线圈复位电压:70%或更低
- 尺寸:20.2 mm x 10.1 mm x 8.0 mm
- 工作温度范围:-40°C~+70°C
