产品详细内容
产品型号: 61-7664-26
产品品牌: NIHON PISCO CO., LTD.
功能
- Controls the speed and air pressure signals of pneumatic equipment.
- Flow rate can be adjusted while air is flowing.
- After mounting, the tube removal angle can be changed by rotating the metal body and the resin body.
- Fluorine grease is d for the grease, and after cleaning with clean air, it is packaged in a clean room (equivalent to ISO class 6).
规格
- 使用的流体:空气
- 使用压力范围:0-0.9MPa
- 使用真空压力:-100kPa
- 作业温度范围:0 -60°C (无结冰)
- 支援RoHS
- 形状:弯管头类型
- 适用管尺寸 (外径) :φ4mm
- 套用螺丝大小 (公制螺丝) :M 5 x 0.8
- 用途:规格:洁净室包装，外观规格:开环 (材质) :浅蓝色 (POM) ，树脂体颜色 (材质) :浅灰色 (PBT) ，金属体材质 (工艺) :黄铜 (化学镀镍)
